Security Cabin with AC (Curved Design) - Abu Dhabi, Mussafa

Durable curved security cabin with AC, insulated walls, and high-quality finishes. Ideal for security personnel, site monitoring, and remote locations in Abu Dhabi.

About Security Cabin with AC (Curved)

This Security Cabin with AC (Curved) is designed to provide a comfortable and secure workspace for personnel across commercial, industrial, and construction environments.
Built with a robust steel base frame, the cabin ensures long-lasting durability and stability. The unit features insulated walls, a high-quality curved roof, and pre-installed electrical provisions, including AC.
Its compact yet functional design makes it ideal for site security, checkpoints, and remote monitoring stations. Delivered to Mussafa, Abu Dhabi, this cabin combines safety, comfort, and convenience in a professional solution.

Inside the Prefabricated Disabled Toilet

Security Cabin with AC (Curved): Project Detail Specification

Size: 3.0m (L) x 2.0m (W) x 3.2m (H)
Location: Abu Dhabi, Mussafa

Base Frame:

Steel floor frame constructed from tubes with central runner and cross members
All steel wire-brushed and coated with one primer layer for protection

Walls:
External Finish: ACP panels
Internal Finish: 12mm thick gypsum board finished with super white emulsion
Insulation: 50mm thick rock wool, 30kg/m³ density

Roof:

50mm Polyurethane Aluminum/GL Sandwich panel
Flat exterior and interior surfaces
PU insulation 35kg/m³, 50mm thick
False Ceiling: 12mm thick gypsum board finished with super white emulsion

Flooring:

Vinyl flooring with skirting
Installed over 18mm cement board subfloor

Doors & Windows:
Door: 1 x Aluminium powder-coated door (80cm W x 200cm H)
Windows:

2 x side fixed-cum-sliding clear glass
1 x fixed clear glass (curved)

Accessories:

Small white MDF table inside

Electrical:

Fluorescent LED light inside
Waterproof LED light outside
Switches and plug points
32A main power inlet
1 x 1.5-ton split AC (Super General or equivalent)
